Powerful dust removal system: Equipped with high-power dust collection device, it can effectively reduce dust pollution and improve the workshop environment.
KINDLE
The plywood sanded by the sanding machine has high surface flatness and low roughness, which can effectively eliminate burrs, unevenness, scratches and other defects on the surface of the board, providing a good foundation for subsequent coating, veneer and other processes, so that the coating or veneer can be more evenly and firmly attached to the surface of the board, improving the beauty and service life of the product.
Machine parameter
Model | ZDR-RP630 | ZDR-RP1000 | ZDR-RP1300 |
Max working width | 630mm | 1000mm | 1300mm |
Material thickness | 2-120mm | 2.5-120mm(option 2.5-160mm) | 2-120mm(option 2.5-160mm) |
Min. Working length | 350mm | 350mm | 350mm |
Feeding speed | 6-30m/min | 6-30m/min | 6-30m/min |
1# sanding belt speed | 18m/min | 18m/min | 18m/min |
2# sanding belt speed | 14m/min | 12m/min | 12m/min |
Size of sanding belt | 650*1900mm | 1020*2020mm | 1320*2020mm |
Main motor power | 11kw,7.5kw | 15kw,11kw | 37kw,22kw |
Total power | 20.74kw | 30kw | 56.74kw |
Working air pressure | 0.5mpa | 0.55mpa | 0.55mpa |
Volume of dust collecting | 5000m3/h | 5500m³/h | 5000m³/h |
Speed of dust collecting | 25-30m/s | 25-30m/s | 25-30m/s |
Overall dimension(L*W*H) | 1700*1100*2050mm | 1700*1400*2050mm | 2750*2200*2050mm |
Weight | 1300kg | 2000kg | 3200kg |
1. The energy consumption of the sanding machine is stable during operation, and there will be no large fluctuations, which is convenient for enterprises to manage energy consumption and calculate costs.
2. The equipment has an overload protection function. When the sanding load is too large, it will automatically stop to avoid equipment damage and extend its service life.
